Proportional Solenoid
DOWNLOAD THE SPECIFICATION
| Model No | GV40-4-AT |
|---|---|
| Rated Voltage（V） | 24 |
| Rated Current（A） | 0.8 |
| Rated Force（N） | 49±0.5 |
| Push rod length（mm） | 10.5±0.15 |
| Hysteresis Magnetic Current（%） | 2 |
| Oil Pressure Duration（MPa） | 21 |
| Resistance（Ω/20℃） | 11.3±1 |
| Push back length（mm） | 7.2±0.15 |
| Hysteresis Magnetic Force（%） | 2 |
| Repetition Precision（%） | 1 |
| Relative Duty Rating（%） | 100 |
| Protection Grade | IP65 |
S—F Characteristic Curve Test Current : 0.8A
-
Within the rated stroke and current, this series solenoids output magnetic force is proportional to the input single. This series solenoid can be matched with the Proportional Control Amplifier to achieve the precise control of the plunger, and is generally used in the proportional spillover valve, proportional decompression valves, proportional compound valves etc with high repetition precision and good linearity plus.
